> 제품소개 > STEEL CHAIN WITH PLASTIC TOP CHAIN

STAINLESS STEEL
CHAIN #60
STEEL CHAIN #60
STEEL CHAIN #40




82

CHAIN TYPE CODE.NO MATERIAL PLATE
WIDTH(K) 		WORKING
LOAD(MAX) 		BACKFLEX
RADIUS(MIN)		 WEIGHT
PLATE PIN MM INCH N R kg/M
SP826ST
SP1143ST

1122
1123

 ACETAL STAINLESS
STEEL		 82.6
114.3		 3.25
4.50		 4950
 285 2.3
2.5
※ Standard length : 3.048m-10feet(80links) ※ TOP PLATE CHAIN 용도는 제과 콘베아용임




82


CHAIN TYPE CODE.NO MATERIAL PLATE
WIDTH(K) 		WORKING
LOAD(MAX) 		BACKFLEX
RADIUS(MIN)		 WEIGHT
PLATE PIN MM INCH N R kg/M
SP635JS
SP826JS
SP1143JS
SP1270JS

1141
1142
1143
1144

ACETAL STAINLESS
STEEL		 63.5
82.6
114.3
127.0 		2.50
3.25
4.50
5.00 		4950 150 2.2
2.5
2.8
3.2
※ Standard length : 3.048m-10feet(80links)




82

CHAIN TYPE CODE.NR MATERIAL PLATE
WIDTH(K) 		WORKING
LOAD(MAX) 		BACKFLEX
RADIUS(MIN)		 WEIGHT
PLATE PIN MM INCH N R kg/M
SP826S
SP1143S
SP1524S
SP1905S

1126
1127
1128
1129

 ACETAL STAINLESS
STEEL		 82.6
114.3
152.4
190.5		 3.25
4.50
6.00
7.50		 4950
4950
4950
4950
 150
150
150
150		 2.10
2.23
2.53
2.68
※ Standard length : 3.048m(80links)
